Brass Heat-Set Threaded Inserts are the gold standard for assembling and securing plastic parts together. When installed, the serrated outer edges grab hold of the plastic that was locally melted around it and make for a reliable and repeatable threaded joint to screw into again and again. Available in the most common sizes for 3D-printed blaster builds (and a few uncommon sizes too). Organized by thread size and length.
Having trouble finding what you're looking for? E-mail us!
FEATURES:
• Brass Heat-Set Threaded Inserts
• Melt-in metal screw joint for plastic parts
• Reliable, repeatable connections
• Designed to be installed with a soldering iron
• M16 x 10mm Inserts can be installed with CA glue
• Available in multiple common (and uncommon) sizes
INCLUDES:
• 1 Heat-Set Insert in the size of your choice
COMPATIBILITY:
• M3 x 3mm: Halo M6G
• M3 x 4mm: Blitz + Riot
• M3 x 6.4mm: Breacher, Juno, Flycore
• #8-32 x 0.312in: Breacher
• #10-32 x 0.4375in: SLAB, Excalibur
• M5 x 7mm: Fidlock HOLD-ster
• M16 x 10mm:
3D DESIGN NOTES:
See phtos for Fusion 360 dialog example.
• M3 x 3mm: 4.9mm hole diameter, 0 degree taper
• M3 x 4mm: 4.9mm hole diameter, -4 degree taper
• M3 x 6.4mm: 5.6mm hole diameter, -4 degree taper
• #8-32 x 0.312in: 6.25mm hole diameter, 7.92mm depth, -8 degree taper
• #10-32 x 0.4375in: 7.3mm hole hole diameter, 11mm depth, -3 degree taper
• M5 x 7mm : 7mm hole diameter, -4 degree taper
• M16: 20-20.5mm hole diameter, 0 degree taper
SPECS:
• Material: Brass
• Dimensions: Varies
• Weight: Varies
