Replacement Aluminum Barrel

Replacement Aluminum Barrel

Regular price $4.49 USD
Regular price Sale price $4.49 USD
Sale Sold out
ID x Length - Blaster

These Replacement Aluminum Barrels are extruded aluminum barrel tubes for spring-powered foam dart blasters. Cut and deburred in-house from quality aluminum tubing, these barrels are a budget-friendly choice for performance blaster builds. Additionally, these barrels are available in multiple different lengths, enabling experimentation and performance tuning.

Having trouble finding what you’re looking for? Email us!

FEATURES:
• Replacement Aluminum Barrels
• Extruded aluminum tubing
• For performance springers
• Cut and deburred in-house

• Designed for most standard-breech springers
• Compatible with SLAB, SMILEY + Caliburn
• Not compatible with Worker Seagull, Harrier, or Kunlun
• 0.495 ID barrel not compatible with most blasters

INCLUDES:
• 1 aluminum barrel in the length of your choice

COMPATIBILITY:
SLAB, SMILEY, Vulture, Talon Claw + more:
• 12.00in: Shortest barrel to accept a SCAR
• 14.00in: +15 FPS with the right spring

Other barrels of note:
• 3.94in: SPAMF
• 9.00in: Foxbat
• 15.50in: Shortest Lynx barrel with slim PCAR
• 18.00in: Longer Caliburn + Lynx barrel

PERFORMANCE:
Average FPS (Standard Deviation) in Silly’s Alchemist
with 2.03 x 140mm spring + 350mm (~14in) barrel
• 233 (5) FPS with 0.527in (13.38mm) barrel
• 244 (2) FPS with 13mm barrel
• 246 (3) FPS with 0.509in (12.93mm) barrel
• 247 (3) FPS with 12.75mm barrel

Average FPS (Standard Deviation) in CS Caliburn 4
with 2.03 x 280mm spring + 350mm (~14in) barrel
• 225 (5) FPS with 0.527in (13.38mm) barrel
• 262 (5) FPS with 12.75mm barrel

SPECS:
• Material: Extruded Aluminum
• Dimensions:
ID: 0.527in (13.38mm)
OD: 0.625in (15.88mm)
Lengths: 3.94-22.5in (100-572mm)
Tolerance: ± 0.015in (± 0.381mm)
• Weight: 94g
• SKU: BARREL_0.527IN

LINKS:
• DASH-016 Collet O-ring
• 140mm Tuning Springs
• Machined Barrels
• All Springer Barrels

View full details
  • 5 stars: 17 (81%)
  • 4 stars: 2 (10%)
  • 3 stars: 1 (5%)
  • 2 stars: 1 (5%)
  • 1 star: 0 (0%)
N
Nate C.
good barrel material

didn't actually use it for an esper, but it works great for a short dart-converted rush 40

C
Christopher M.
Quality parts at a good price.

Out of Darts had all the pieces I needed, quickly shipped to my door at a great price. I will definitely buy from them in the future.

S
Shane

A little delayed but still came in within a few days

k
kyle f.

quick and timely shipping will order from again

A
Anthony

A little bit loose on the darts but does it's job

A
Anonymous
Switched out with shorter barrel. Worked perfect

Just put a longer barrel on my ontos. Only did it for the look. Lokks better with a longer barrel.

J
J.H.

This aluminum barrel was the perfect size! It was exactly what I needed to finish off modding my xshot fury x. The wait was most definitely worth it and the wait was actually pretty short, would recommend, 5 stars! 😁

D
Daniel

Great

J
Jaelan

Arrived as pictured.

P
Pugsley
Needs Deburring, But Overall Excellent

These barrels are excellent for their price! I love the chamfered ends, as it helps to avoid jams, as long as you sand them a little first. The ends are a little ragged. Just hit em up with a sanding sponge to debur and you're good to go!

E
Elijah

Works great for my ontos build!

C
Cameron

UPDATE: After talking support, they sent me another one. I understand now that this is a budget product and that I should temper my expectations. The issues below were still present on the new one, but they were less so, the sticker still stuck but the deburring on the ends was better.
It’s a barrel, the label sticker left residue I had to scrape off. I nearly cut myself on the burrs left on the chamfers, there was a lot of jagged aluminum and the chamfering was way worse than the stock NPX barrel. The chamfer was inconsistent in depth too. Other than that it was a functioning straight barrel.

J
James

Excellent quality

D
Dylan C.

very good

H
Henrik

Good

H
Henrik

Exactly what I expected and even better and arrived quicker then i imaged.

Q
Quinn L.
Barrel fit is dookie

All seems fine about the barrel except the fit, darts fall right through with 0 resistance, too late to return now though.

Hi Quinn,
We're sorry to hear you're having issues witha barrel. We do offer multiple inner diameters for a variety of builds including .507 ID, .527 ID and 16mm ID. Each has pros and cons depending on the darts and blaster they are installed in. E-mail us directly for help with a no cost replacement if yours didn't work for your purpose.

J
James S.
High quality barrel

used this (18" version) for my cynthia build and just to have in case of future projects. In my case the cynthia doesnt have quite a large enough plunger tube volume for this barrel to reach its maximum potential so I personally didnt get much "extra" power out of it but I did get a decrease in sound and a very slight increase in consistency. I wish they had the version of these barrels with the slightly opened end to allow the breach and its o-rings to fit perfectly

P
Pascal S.A.
Good Product

I swapped this barrel with a stock trion barrel, and although the accuracy greatly improved, the fps took a decent dip.

N
Nicholas T.
Good barrel

Nice and consistent performance with worker and dart zone darts

O
Oliver N.
Does what it does

It's a replacement barrel. It works.

T
Trenton

Are these barrels 16mm in diameter?

Out of Darts

Hi Trenton,

These barrels are 16mm in diameter.

Happy Modding,

OUT OF DARTS / Jessica
orders@outofdarts.com
www.outofdarts.com
