JST PH 2.0mm 2-Pin Connectors

The JST PH 2.0mm 2-Pin connector is a low-current wire terminal commonly used in the nerf-modding hobby. With solderless, crimped brass conductors and a polarized nylon-insulated shroud, this connector works well as signal wires for MOSFETs and limit switches, or for modular, swappable N20 motors using our N20 PCB! Additionally, the JST connector and its 26 AWG wire are thin enough to fit in small gaps alongside higher-current hobby wire.

Below are all our currently available JST PH 2.0 2-pin connectors, available in a variety of types to purchase for maintenance or repair of select blasters, or for custom mod projects. Having trouble finding what you’re looking for? Email us!

FEATURES:
• JST PH 2.0 2-Pin Connectors
• Solderless low-current terminal
• Great for signal wires + limit switches
• Low-profile connector + wiring
• Polarized connection*
• Compatible with most MOSFETs
• Compatible with N20 PCB

*Note: Polarity often does not matter with low-voltage switching components, but double-check before installing!

INCLUDES:
• 1 JST PH 2.0 Connector in the style of your choice

SPECS:
• Current: Up to 2A
• Voltage: Up to 3S (~12V)
• Wiring: up to 24 AWG (26 AWG used)
• Pitch: 2.0mm
• Materials: Brass, Nylon, PVC
• Dimensions: ~7.6 x 5.9 x 4.6 mm
• Weight: 0.13g
• SKU: CONNECTOR JST PH 2.0
